2.00 mm Pitch Box Header Connector

Note: Available with various mounting options including solder hold-downs, mounting pegs, and locking latches. Custom pin counts and plating options available.

1. High-Density Design for Space-Constrained PCBs
Featuring a standard 2.0mm pitch, this connector supports single row (2–40 pins) and dual row (4–80 pins) configurations, allowing more connection points within limited PCB space. With through-hole, SMT, and right-angle mounting options available, it meets diverse layout requirements and helps you maximize design density.

2. Robust Power Delivery with Reliable Electrical Performance
Each contact delivers a rated current of 2A to 3A, with insulation resistance ≥1000MΩ and dielectric withstand voltage of 250V AC/DC. Whether used in industrial control systems or power equipment, this connector ensures stable signal integrity and safe power transmission even under demanding conditions.

3. Premium Materials for Durability and Safety
Contacts are made of phosphor bronze or brass with gold or tin plating over nickel, achieving contact resistance ≤20mΩ and extended mating life. The housing is constructed from PBT or PA6T with UL94V-0 flame rating, meeting rigorous safety standards while providing excellent mechanical durability.

4. Multiple Packaging Options for Efficient Production
Available in tube, tape and reel, or tray packaging, this connector supports both manual soldering and automated SMT/through-hole assembly processes. From small-batch prototyping to high-volume mass production, it seamlessly integrates into your manufacturing workflow to boost efficiency.

• Pin Configurations: Single row (2-40 pins) or dual row (4-80 pins)
• Mounting Styles: Vertical (straight), right-angle (90°), or SMT
• Contact Plating: Tin (standard), gold flash (0.1μm), selective gold (0.3-0.8μm)
• Housing Features: Polarization posts, mounting pegs, solder tabs
• Locking Options: Friction lock, latch lock, or ejection mechanisms
• Color Coding: Black (standard), white, gray, or custom colors
• Packaging: Tube, tape and reel (SMT), or bulk
• Special Features: Pick-and-place compatible, high-temperature materials

Compact Shrouded Connections for Space-Constrained Systems

• Industrial Control & Automation: Used in PLC modules, motor drives, and I/O cards where the 2.0mm pitch provides high density while the shrouded design protects pins during field installation.
• Consumer Electronics: Deployed in set-top boxes, gaming consoles, and home appliances requiring reliable internal connections in compact spaces.
• Automotive Electronics: Used in infotainment systems, body control modules, and dashboard displays where vibration resistance and reliable connections are essential.
• Medical Devices: Integrated into patient monitors, diagnostic equipment, and portable medical devices requiring compact, reliable interconnections.
• Telecommunications Equipment: Deployed in routers, switches, and base station modules for internal board-to-board and wire-to-board connections.
• Test & Measurement: Used in benchtop instruments and automated test equipment requiring dense, reliable signal routing.
• LED Lighting & Displays: Integrated into LED driver boards and display panels for control signal distribution.
• Security Systems: Deployed in access control panels and surveillance equipment requiring reliable internal connections.

1.Mike, controls engineer in Ohio
"Been using these 2.0mm box headers on our PLC I/O modules for years. The shrouded design saves us from bent pins during assembly-big improvement over open headers. The 2.0mm pitch gives us good density without being too tight. Good quality, consistent across batches."

2.Carlos, medical device tech in Texas
"Portable patient monitors need compact but reliable connections. These 2.0mm headers with dual row provide enough I/O in small footprint. The shrouded design prevents mis-mating during field repairs. Good quality, no failures."

3.Tom, telecom hardware guy in California
"Using these on router line cards. The 2.0mm pitch allows 80 pins in small board area. Right-angle version works for our mezzanine card design. The tin-plated version is cost-effective for high volume. Consistent quality."

4.Yuki, robotics hobbyist in Tokyo
"Using these on custom robot controller boards. The 2.0mm pitch is easier to hand-solder than 1.27mm. The box shroud protects pins when swapping modules. Good quality for the price.
