1.27 mm Pitch Box Header Connector

Note: Available with various mounting options including solder hold-downs and mounting pegs. Custom pin counts and plating options available.

1. Compact 1.27mm Pitch for High-Density PCB Designs
Features a space-saving 1.27mm (0.050 inch) pitch supporting single row (2 to 50 pins) and dual row (4 to 100 pins) configurations - maximizing connection density on space-constrained PCBs. Perfect for telecommunications equipment, data storage systems, industrial controls, and compact electronic devices.

2. Versatile Mounting Options for Any Assembly Process
Available in through-hole, surface mount (SMT), and right-angle mounting styles to suit your PCB layout and manufacturing requirements. Compatible with manual soldering, wave soldering, and reflow processes - providing design flexibility for diverse applications.

3. Reliable Electrical Performance for Signal Transmission
Rated at 1A to 1.5A per contact with 100V to 125V AC/DC - ideally suited for signal transmission and low-power applications. Phosphor bronze contacts with gold or tin plating over nickel ensure low contact resistance and excellent corrosion resistance.

4. High-Temperature Housing with UL94V-0 Flame Rating
Housing molded from PBT or PA6T with UL94V-0 flame rating provides excellent thermal stability and fire safety. Available in tube, tape and reel, or tray packaging to support manual assembly or high-speed automated production lines.

• Pin Configurations: Single row (2-50 pins) or dual row (4-100 pins)
• Mounting Styles: Vertical (straight), right-angle (90°), or SMT
• Contact Plating: Gold flash (0.1μm), selective gold (0.3-0.8μm), or tin
• Housing Features: Polarization posts, mounting pegs, solder tabs
• Color Coding: Black (standard), white, gray, or custom colors
• Packaging: Tube, tape and reel (SMT), or bulk
• Special Features: Pick-and-place compatible, high-temperature materials

High-Density Shrouded Connections for Space-Constrained Systems

• Industrial Control & Automation: Used in compact PLC modules, sensor interfaces, and I/O cards where high pin density is required in limited board space.
• Medical Devices: Deployed in portable patient monitors, diagnostic equipment, and handheld medical instruments requiring reliable, compact interconnections.
• Consumer Electronics: Used in smartphones, tablets, wearable devices, and portable audio equipment where space optimization is critical.
• Telecommunications Equipment: Integrated into routers, switches, and network modules for high-density internal connections.
• Test & Measurement: Used in benchtop instruments and portable test equipment requiring dense signal routing.
• Embedded Systems: Deployed in single-board computers, industrial controllers, and IoT gateways requiring compact board-to-board connections.
• Automotive Electronics: Used in infotainment systems, advanced driver assistance systems (ADAS), and body control modules where space is limited.
• Aerospace & Defense: Integrated into avionics, communication systems, and portable military equipment requiring high reliability in compact form factors.
