Construction
|
Conductor |
Insulator |
Electrical characteristic |
||||
|
AWG |
construction |
Diameter |
Insulator Thick |
Over Diameter Mm |
Conductor Resistance |
Permissible |
|
30(0.05mm²) |
11x0.08 |
0.306 |
0.247 |
0.8 |
316 |
0.55 |
|
28(0.08mm²) |
16x0.08 |
0.369 |
0.415 |
1.2 |
217 |
0.75 |
|
26(0.15mm²) |
30x0.08 |
0.506 |
0.50 |
1.5 |
116 |
1.5 |
|
24(0.20mm²) |
40x0.08 |
0.584 |
0.50 |
1.6 |
87.1 |
2 |
|
22(0.30mm²) |
60x0.08 |
0.715 |
0.49 |
1.7 |
58.0 |
3 |
|
20(0.50mm²) |
100x0.08 |
0.924 |
0.438 |
1.8 |
34.8 |
5 |
|
18(0.75mm²) |
150x0.08 |
1.13 |
0.68 |
2.3 |
23.3 |
7.5 |
|
17(1.00mm²) |
210x0.08 |
1.33 |
1.40 |
2.7 |
16.6 |
10.5 |
|
16(1.27mm²) |
252x0.08 |
1.46 |
0.77 |
3.0 |
13.9 |
12.6 |
|
15(1.50mm²) |
300x0.08 |
1.60 |
0.80 |
3.2 |
11.6 |
15 |
|
14(2.00mm²) |
400x0.08 |
1.85 |
0.825 |
3.5 |
8.7 |
20 |
|
13(2.50mm²) |
500x0.08 |
2.06 |
0.97 |
4.0 |
6.96 |
25 |
|
12(3.40mm²) |
680x0.08 |
2.40 |
1.05 |
4.5 |
5.1 |
34 |
|
11(3.76mm²) |
750x0.08 |
2.53 |
1.25 |
5.0 |
4.6 |
37.5 |
|
10(5.27mm²) |
1050x0.08 |
2.99 |
1.30 |
5.5 |
3.4 |
52.5 |
|
9(6mm²) |
1200x0.08 |
3.20 |
1.40 |
6.0 |
2.90 |
6 |
|
8(8.25mm²) |
1650x0.08 |
3.75 |
1.40 |
6.5 |
2.10 |
82.5 |
|
7(10mm²) |
2400x0.08 |
4.50 |
1.40 |
7.2 |
1.45 |
120 |
|
6(16mm²) |
3200x0.08 |
5.20 |
1.65 |
8.5 |
1.08 |
128 |
|
5(20mm²) |
4000x0.08 |
5.85 |
1.82 |
9.5 |
0.87 |
160 |
|
4(25mm²) |
5000x0.08 |
6.55 |
2.75 |
11.5 |
0.70 |
200 |
|
3(35mm²) |
7000x0.08 |
7.73 |
2.63 |
12.6 |
0.50 |
280 |
|
2(50mm²) |
10000x0.08 |
9.25 |
2.87 |
15.0 |
0.35 |
300 |
|
10mm² |
2000x0.08 |
4.13 |
1.28 |
6.7 |
1.75 |
100 |
|
70mm² |
14000x0.08 |
10.9 |
3.05 |
17 |
0.248 |
350 |
|
95mm² |
21000x0.08 |
12.7 |
3.40 |
20 |
0.183 |
380 |
|
120mm² |
24000x0.08 |
14.3 |
2.84 |
21 |
0.145 |
480 |
|
150mm² |
30000x0.08 |
16.0 |
4 |
24 |
0.12 |
525 |
Note: Custom conductor stranding, insulation materials, colors, and packaging can be specified.
electronic wire Customization Options
We offer comprehensive customization to meet your specific wiring needs:
- Conductor Configuration: Solid core for fixed installations or multi-strand for flexible applications
- Conductor Material: Bare copper (standard), tinned copper (corrosion resistance), or custom
- Insulation Types: PVC, TPE, PUR, teflon or custom
- Color Coding: Standard 10+ colors, custom colors, or printed wire markings
- Packaging: Spools (100m,305m, 500m), coils, cut lengths, or custom
- Special Features: Shielded versions, twisted pairs, bonded parallel cables, or pre-stripped ends
electronic wire Applications
Versatile Interconnect Solutions for Electronics Manufacturing
- Consumer Electronics: Internal wiring for TVs, audio equipment, home appliances, and chargers
- Industrial Control Systems: Panel wiring, sensor connections, PLCs, and motor controls
- Automotive Electronics: Wiring harnesses, lighting, infotainment, and engine control units
- Telecommunications: Equipment internal wiring, patch panels, and network devices
- Medical Devices: Patient monitoring equipment, diagnostic instruments, and portable medical electronics
- Renewable Energy: Solar panel interconnections, wind turbine controls, and battery systems
