Construction
Construction:(USB2.0 USB3.0)
|
AWG |
Conductor |
No.of |
Insulation |
Braid Shield |
Jacket |
0verall |
|
28 |
7/0.127 |
1P |
0.80～0.90 |
16/5/0.1 |
0.23 |
4.5～4.6 |
|
28 |
7/0.127 |
2C |
0.85 |
|||
|
28 |
7/0.127 |
1P |
0.80～0.90 |
16/5/0.1 |
0.23 |
4.7～4.8 |
|
26 |
7/0.160 |
2C |
1.0 |
|||
|
28 |
7/0.127 |
1P |
0.80～0.90 |
16/5/0.1 |
0.23 |
4.8～4.9 |
|
24 |
7/0.200 |
2C |
1.1 |
|||
|
25 |
7/0.190 |
1P |
1.05～1.15 |
16/6/0.1 |
0.23 |
5.2～5.5 |
|
22 |
7/0.254 |
2C |
1.3 |
|||
|
25 |
7/0.190 |
1P |
1.05～1.15 |
16/6/0.1 |
0.23 |
5.3～5.6 |
|
20 |
7/0.320 |
2C |
1.5 |
Construction:(USB3.1)
|
AWG |
Conductor |
ID |
NO.of Core |
OD |
Length for use |
|
34 |
7/0.06 |
0.47 |
4P+1P+4C+2C |
4.2 |
1.0 |
|
32 |
7/0.08 |
0.58 |
5.0 |
1.5 |
|
|
30 |
7/0.10 |
0.70 |
5.5 |
2.0 |
|
|
28 |
7/0.127 |
0.90 |
6.0 |
2.5 |
|
|
26 |
7/0.16 |
1.20 |
6.5 |
3.0 |
Electrical Characteristics of USB Cable
|
No. |
Parameter |
Recommended Test Conditions |
Recommended Specifications |
||
|
USB 2.0 |
USB 3.0 |
USB 3.1 |
|||
|
1 |
Differential |
TDR |
90 Ω±15%/200ps |
90 Ω±7Ω/200ps(cable) |
90 Ω±5Ω/200ps(cable) |
|
2 |
Propagation |
TDR |
5.2ns/m |
/ |
/ |
|
3 |
Skew |
TDR |
100ps/cable (max)200ps |
15ps/m(max)200ps |
15ps/m(max)200ps |
|
4 |
Data Rate |
/ |
Max>480Mbps |
Max>5Gbps |
Max>10Gbps |
USB Raw Cable Series
Our USB Raw Cable can be tailored to meet your integration needs:
- USB Configuration: Standard 4-conductor (USB 2.0), 9-conductor (USB 3.x), or full 24-conductor (USB-C)
- Shielding Options: Basic foil, braid, double shielding, or unshielded for specific applications
- Jacket Types: PVC (standard), TPE (flexible), PUR (oil-resistant), or LSZH (low smoke zero halogen) or custom
- Color Selection: Black, white, gray, blue, red, or custom color matching
- Packaging Format: Bulk reels (100m, 305m, 500m), cut lengths, or pre-stripped ends
USB Raw Cable Applications
Versatile Cable for Custom Connectivity Solutions
- Custom Cable Assembly: Feedstock for manufacturing custom-length USB cables with specialized connectors
- Electronics Integration: Internal wiring for printers, monitors, POS systems, and consumer electronics
- Industrial Control Systems: Machine wiring, HMI connections, and equipment interfacing
- Prototype Development: Flexible cabling for R&D, testing, and prototype construction
- Automotive Electronics: Wiring harness integration for infotainment and diagnostic systems
- Medical Equipment: Internal connections for portable devices and diagnostic instruments
Our Advantages
1)Experienced in interface connectors and cable assemblies, we can offer a wide range of standard production capabilities such as stamping, injection molding, prototype, connectors and cable assemblies, customized connectors and cable assemblies, and custom retail packaging.
2)Advancing interconnect technology. Our team can offer a world-class interconnect experience from initial consultation to final delivery to meet solutions for our customer's interconnect challenge, our personalized design and engineering package include CAD drawings, 3D models, prototypes and testing samples.
3)Building connections worldwide. We can provide a wide range of interconnect solutions in order to meet the needs of customers in many different types of markets,some of the most popular markets such as:high-end consumer electronics, data storage, set-top box, medical, home security,industrial, audio/video, desktop and mobile computer units.
4)High quality products and competitive pricing.
5)Exceeding expectations. our Quality Policy is Quality First, Customer First.
